Ziehm Imaging, Inc. QUANTUM User Manual

Section 15.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 209 of 220
13a Image intensifier position patient
orientation
1
13b Label position Generator patient
orientation
1
14
Only on systems with Laser
device
Background is Yellow in color
Location see fig 15.2
3
15
Only on systems with Laser
device
Background is Yellow in color
Location see fig 15.2
2
16
Only on systems with Laser
device
Background is Yellow in color
Location see fig 15.2
2
17
Only on systems with Laser device
* Qty 1 for Laser LG
*Qty 2 for Laser LC
Background is Yellow in color
Location see fig 15.2
*
