SWT
GIGABIT/FAST ETHERNET SWITCH TYPE SWT 41/137
USER GUIDE - M0SWTA1903Iv09 - V09 March 2019
5.1 GENERAL PARAMETERS
The general parameters are grouped on the first page, see FIGURE 23, which is shown
when the SWT validates the user identity.
In addition to the configuration parameters, which will be described in the following
sections, as shown in the figure, the system provides information about the equipment
software, that is to say, version being executed, and equipment hardware, that is to say,
serial and tracking number.
The tree menu is permanently located on all the pages used by the HTTP server.
FIGURE 23 Main HTML page
