SWT
GIGABIT/FAST ETHERNET SWITCH TYPE SWT 90/137
USER GUIDE - M0SWTA1903Iv09 - V09 March 2019
6 STATISTICS
The system provides statistics divided into six blocks, each of them corresponding to a
specific functionality.
The first block shows general information related to the equipment, and is displayed
automatically when the statistics object is selected.
The remaining statistics are grouped into data on the Ethernet (Ports) interfaces, the MAC
addresses identified by the switch, STP protocol, LLDP protocol and the synchronization
client (NTP), each of which can be accessed by selecting the respective tag located under
the heading Statistics.
Each statistical data table can be updated by pressing the Reload button without having
to select the respective option again in the tree menu.
The statistics can be REBOOTED by the user at will, from the console by executing the
clear command in the prompt, or using the menu option Clear Statistics.
