SWT
GIGABIT/FAST ETHERNET SWITCH TYPE SWT 46/137
USER GUIDE - M0SWTA1903Iv09 - V09 March 2019
5.4 ETHERNET PORTS CONFIGURATION
The Ports menu permits the configuration of the operating parameters of the Gigabit/Fast
Ethernet ports in the equipment, and the assigning of each port to one of the VLANs
defined in the equipment (see section 5.5).
By default, Web management is accessible from the interfaces assigned to vlan1. As a
factory setting, all Gigabit/Fast Ethernet ports have a default VLAN id (VID) of value 1.
If the default VID of a given port is changed, the Web management will no longer be
accessible from that port.
FIGURE 26 Ports menu configuration page
