SWT
GIGABIT/FAST ETHERNET SWITCH TYPE SWT 40/137
USER GUIDE - M0SWTA1903Iv09 - V09 March 2019
5 CONFIGURATION AND MANAGEMENT
Configuration and management of the SWT is performed through the console and through
access to the equipment HTML pages.
All the parameters controlling the equipment operation are described below in detail, using
the real HTML pages, as shown in the auxiliary graph.
Whenever changes are made, regardless of whether they are made through the console
or the HTTP server, the equipment must be informed what is to be done with them.
There are two options:
- the first is to execute the Apply command, which entails the immediate use of the
changes made.
- the second is to execute the Save command, which means that the changes will be
operative once the equipment is rebooted.
If accessing through the HTTP server, after making the changes and before executing
Apply or Save, the Send button must be pushed to allow the equipment to obtain the
new desired values.
If executing the Apply command, if the changes are required to be permanent, the Save
command must also be executed.
The only exceptions are changes affecting the SNMP configuration. Changes made to
the SNMP agent configuration will only be active after RESETTING the equipment. The
Apply command is not sufficient, and so the changes must previously be saved using
the Save command before requesting the re-initialisation.
