SWT
GIGABIT/FAST ETHERNET SWITCH TYPE SWT 88/137
USER GUIDE - M0SWTA1903Iv09 - V09 March 2019
5.19.1 Upload (from the PC to the equipment)
The user must select the file containing the configuration to be uploaded by pressing the
button Examine.
In order to only verify the configuration without upload it, the Only verify box must be
ticked.
Once the equipment has received the file, the system checks the file contents and verifies
that the variables are valid and that the values assigned to them comply with the existing
syntactic requirements. If errors are detected in the received file, irrespective of whether the
Only verify option is selected or not, the system automatically rejects all the information
received and indicates the error situation to the user.
If the received configuration is valid, it is indicated by the system to the user, and it is then
possible to continue (Continue button). When continue is selected, the configuration is
activated and stored.
When applying the new configuration, the system issues a warning due to the possible
loss of equipment access.
If the Only verify option has been selected, and verification has been successful, it is
indicated by the system to the user. If desired, the configuration can be applied by means
of the Apply and Save commands or both.
5.19.2 Download (from the equipment to the PC)
With this option the user obtains a local copy of the operating configuration in .txt format or
.xml format.
The procedure for downloading this file depends on both the HTTP browser and the actions
to perform with the received file (for example, where to store it).
