SWT
GIGABIT/FAST ETHERNET SWITCH TYPE SWT 64/137
USER GUIDE - M0SWTA1903Iv09 - V09 March 2019
• User: Parameter associated with SNMPv3. Tabulate information that allows the
users, including the privileges and the operating mode associated with each user,
to be defined. That is to say, the rights of access (Access), read only rights (ro) or
reading/writing rights (rw), and the way in which the data transference (Security)
will be carried out, without encryption (clear), authentication (auth) or authentication
and encryption (priv).
In case of authentication transmission (auth), it is necessary to select the type of
algorithm (Auth Alg.), MD5 or SHA, and establish the authentication password
(Auth Password). The password establishes the word to be used to generate the
authentication information. The authentication word must be known by the receiver
in order to be able to verify the authenticity of the identity of the transmitter.
In case of encrypted transmission (priv), in addition to select the type of
authentication algorithm (Auth Alg.) and authentication password (Auth Password),
it is necessary to select the cipher algorithm (Priv Alg.), DES o AES, and establish
the cipher password (Priv Password).
The password is not shown for security reasons and so when it is changed
(Change option), it must be entered twice.
Once the Password is introduced from the Change option, execute the send
command of said option, and then, if you want the password to be applied and
saved in the equipment, DO NOT forget to execute the apply and save
commands from the main menu tree.
FIGURE 35 SNMP menu configuration page
