SWT
GIGABIT/FAST ETHERNET SWITCH TYPE SWT 76/137
USER GUIDE - M0SWTA1903Iv09 - V09 March 2019
Unlike purely manual operation, the execution of the protocol involves the automatic
propagation of application manually set towards the rest of the switches in the network,
so it is only necessary to configure the multicast address on the equipment on which the
interface is involved.
Additionally, the GMRP protocol also applies this type of manual configuration in an
abstract group address, called Forward All, which means than an interface wants to
receive all multicast traffic. This option is configured individually for each local interface of
the equipment.
FIGURE 42 GMRP configuration page of Multicast menu
The parameters are the following:
GMRP:
A single parameter to indicate the implementation of GMRP protocol:
• Enable. A simple CheckBox parameter, which controls the execution of the protocol.
