SpeedFace-V5L [TI] User Manual
Page | 45 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Function Description
Function Name
Descriptions
Wiegand Format
Values range from 26 bits, 34 bits, 36 bits, 37 bits, and 50 bits.
Wiegand Bits
Number of bits of Wiegand data.
Pulse Width(us)
The value of the pulse width sent by Wiegand is 100 microseconds by default, which
can be adjusted within the range of 20 to 100 microseconds.
Pulse
Interval(us)
The default value is 1000 microseconds, which can be adjusted within the range of
200 to 20000 microseconds.
ID Type
Select between User ID and card number.
Various Common Wiegand Format Description:
Wiegand Format
Description
Wiegand26
ECCCCCCCCCCCCCCCCCCCCCCCCO
Consists of 26 bits of binary code. The 1
st
bit is the even parity bit of the 2
nd
to 13
th
bits, while the 26
th
bit is the odd parity bit of the 14
th
to 25
th
bits. The 2
nd
to 25
th
bits
are the card numbers.
Wiegand26a
ESSSSSSSSCCCCCCCCCCCCCCCCO
Consists of 26 bits of binary code. The 1
st
bit is the even parity bit of the 2
nd
to 13
th
bits, while the 26
th
bit is the odd parity bit of the 14
th
to 25
th
bits. The 2
nd
to 9
th
bits
are the site codes, while the 10
th
to 25
th
bits are the card numbers.
Wiegand34
ECCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCO
Consists of 34 bits of binary code. The 1
st
bit is the even parity bit of the 2
nd
to 17
th
bits, while the 34
th
bit is the odd parity bit of the 18
th
to 33
rd
bits. The 2
nd
to 25
th
bits
are the card numbers.
Wiegand34a
ESSSSSSSSCCCCCCCCCCCCCCCCCCCCCCCCO
Consists of 34 bits of binary code. The 1
st
bit is the even parity bit of the 2
nd
to 17
th
bits, while the 34
th
bit is the odd parity bit of the 18
th
to 33
rd
bits. The 2
nd
to 9
th
bits
are the site codes, while the 10
th
to 25
th
bits are the card numbers.
Wiegand36
OFFFFFFFFFFFFFFFFCCCCCCCCCCCCCCCCMME
Consists of 36 bits of binary code. The 1
st
bit is the odd parity bit of the 2
nd
to 18
th
bits, while the 36
th
bit is the even parity bit of the 19
th
to 35
th
bits. The 2
nd
to 17
th
bits
are the device codes. The 18
th
to 33
rd
bits are the card numbers, and the 34
th
to 35
th
bits are the manufacturer codes.

ZKTeco SpeedFace-V5L TI Specifications

General

Device Type	IP Access Controller
Model	SpeedFace-V5L TI
Fingerprint Capacity	10, 000
Card Capacity	10, 000
RFID Capacity	10, 000
Transaction Capacity	200, 000
Logs Capacity	200, 000
Display	5-inch Touch Screen
Wiegand Signal	Wiegand Input/Output
Temperature Detection	Yes
Palm Capacity	3, 000
Communication	TCP/IP, Wi-Fi
Interfaces	RS485, USB Host
Authentication Method	Face, Palm, Card, Fingerprint, Password
Face Recognition Speed	<0.3s
Power Supply	12V 3A
Face Capacity	6, 000 (1:N)
