SpeedFace-V5L [TI]
User Manual
Page | 46 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
Wiegand36a
EFFFFFFFFFFFFFFFFFFCCCCCCCCCCCCCCCCO
Consists of 36 bits of binary code. The 1
st
bit is the even parity bit of the 2
nd
to 18
th
bits, while the 36
th
bit is the odd parity bit of the 19
th
to 35
th
bits. The 2
nd
to 19
th
bits
are the device codes, and the 20
th
to 35
th
bits are the card numbers.
Wiegand37
OMMMMSSSSSSSSSSSSCCCCCCCCCCCCCCCCCCCE
Consists of 37 bits of binary code. The 1
st
bit is the odd parity bit of the 2
nd
to 18
th
bits, while the 37
th
bit is the even parity bit of the 19
th
to 36
th
bits. The 2
nd
to 4
th
bits
are the manufacturer codes. The 5
th
to 16
th
bits are the site codes, and the 21
st
to 36
th
bits are the card numbers.
Wiegand37a
EMMMFFFFFFFFFFSSSSSSCCCCCCCCCCCCCCCCO
Consists of 37 bits of binary code. The 1
st
bit is the even parity bit of the 2
nd
to 18
th
bits, while the 37
th
bit is the odd parity bit of the 19
th
to 36
th
bits. The 2
nd
to 4
th
bits
are the manufacturer codes. The 5
th
to 14
th
bits are the device codes, and15
th
to 20
th
bits are the site codes, and the 21
st
to 36
th
bits are the card numbers.
Wiegand50
ESSSSSSSSSSSSSSSSCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCO
Consists of 50 bits of binary code. The 1
st
bit is the even parity bit of the 2
nd
to 25
th
bits, while the 50
th
bit is the odd parity bit of the 26
th
to 49
th
bits. The 2
nd
to 17
th
bits
are the site codes, and the 18
th
to 49
th
bits are the card numbers.
“C“ denotes the card number; “E” denotes the even parity bit; “O” denotes the odd parity bit;
“F“ denotes the facility code; “M” denotes the manufacturer code; “P” denotes the parity bit; and “S”
denotes the site code.
