Zmorph FAB User Manual

Zmorph Fab - QUICK START GUIDE 14
Single Extruder Toolhead 1.75mm
8. Single Extruder Toolhead 1.75mm
8.1 Loading the lament

0,5 kg spool is included
in the package. Take out

plastic foil, remove moisture
absorber.


looking at the sticker on the


Slide spool on the bar and
place it on the machine.

Choose the ‘MAINTENANCE’
from the LCD touchscreen
menu.
Choose ‘LOAD FILAMENT’. 
the machine to position the
toolhead. When done, choose

NEW JOB MAINTENANCE
LOAD
FILAMENT
CHANGE
TOOL
CALIBRATE
3D PRINTING
BACK MORE
LOAD/UNLOAD
PLA
ABS
PLA
ABS
PET
CUSTOM
TEMPERATURE
COOL
DOWN
TEMPERATURES
PARK
TOOL
BACK
  

NOTE

Zmorph FAB Specifications

General

Build Volume	250 x 235 x 165 mm
Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Print Speed	up to 100 mm/s
Software	Voxelizer
Dimensions	530 x 555 x 480 mm
Layer Resolution	0.05 - 0.3 mm
Connectivity	USB, Ethernet
Supported Materials	PLA, ABS, PETG, TPU, Nylon
Power Supply	24V DC
Print Technology	Fused Filament Fabrication (FFF)
Extruder Type	Single Extruder
Display	5-inch capacitive touchscreen
