Zmorph i500 - Replacing the Extruder hotend

Product Manual - ZMORPH i500 back to table of content >>
52
Service instructions
11.3.1 Replacing the Extruder hotend
From the main menu go to the MAINTENANCE screen,
choose MOVE AXES menu and press “Z Movement”,
park the heated bed at bottom position and then turn
o the machine.
Disconnect the cooling fan wires
from extruder module.
Detach the front cooling fan by pulling it
out (it is mounted by magnets).
11.3 Service instructions
Disconnect the hotend thermistor
and heater wires.
