3.2 I Installing the POD kit
The POD Kit is a measuring chamber using patented Quick Fix® technology for installaon on a rigid 50 mm PVC pipe
(with supplied adapter) or 63 mm PVC pipe (without adapter). It contains the following components:
: Flow switch
: pH sensor
: ORP sensor
: pH minus injecon
: Sensor holder
3.2.1 Recommended posioning
• The cell bypass valves must always be open.
• The sensor-holding POD kit must always be posioned on a horizontal pipe so that the sensors
are vercal.
• The POD kit must be the rst unit ed aer the pool lter.
• If the pool is ed with an electric heater, the POD kit must be installed upstream of the
heater (to take readings on unheated water).
• We recommend posioning the POD kit more than 20 cm from an elbow in the pipe.
• The sensor cables must not be posioned near high voltage mains electricity cables.
Recommended
pool grounding
Recommended
pool grounding
In-line installaon Installaon on a by-pass
• If an electric heater is installed (instead
of a heat pump), place the POD kit
before this heater (in order to measure
unheated water). In this case, the ow
switch must be placed on the bypass on
the xture collar.
Recommended
pool grounding
Installaon with a heang system
