8.3 I Eects of the stabilising agent on chlorine and ORP
A pool ideally has a stabiliser level of 30 ppm and a pH of 7.4.
1 ppm of free chlorine = 700 mV
The user can therefore adjust the chlorinaon requirements to 700 mV to maintain a level of 1 ppm in the pool.
If the level of stabiliser rises to 90 ppm, the ORP value will be incorrect.
1 ppm of free chlorine = 500 mV
If the user keeps the setpoint at 700 mV, a chlorine concentraon of 5 ppm will eventually be obtained!
CHLORINE LEVEL (PPM)
ORP MEASUREMENT (MV)
Variaons in the ORP measurement depending
on the stabiliser concentraon (pH 7.4, 25°C)*.
Setpoint
Stabiliser level
of 90 ppm
Stabiliser level
of 30 ppm
* Theorecal values for informaon purposes only. Real values may vary
slightly depending on the type of water in the pool.
8.4 I HELP menu
The appliance automacally reports any problems by way of informaon messages. To make these messages easier to
understand, the appliance has a troubleshoong menu which gives the meanings and the acons to be taken to resolve
the problem.
• Press and browse the menu using the buons. Press to conrm.
• Select the error message using the buons. Press to conrm.
• The screen automacally scans a certain number of proposed soluons in order to provide explanaons.
Once automac scanning is complete, the appliance automacally returns to the troubleshoong menu.
• Press to exit.
