2.5 I Electrical connecons
Many devices can be connected to the control box in order to control the pool equipment (lter pump, lighng, auxiliary
systems, etc.).
The appliance must be permanently plugged in to the power supply (power supply protected by a 30 mA residual current
circuit breaker).
• Turn the appliance o. Before beginning, disconnect all potenal power supplies to the
appliance.
2.5.1 Accessing the electrical terminal blocks
• Make sure that the appliance is powered o.
• Remove the aesthec housing from the control box (clipped in place), (see gure ).
• Remove the boom protecve cover from the appliance by unscrewing the 2 side screws (see gure ).
