❸ Installing a pH Link or Dual Link module
3.1 I Installing the module
• Turn the appliance o. Before beginning, disconnect all potenal power supplies to the
appliance.
• Close the isolang valves in the pipework.
• Remove the cover and unscrew (x2) the boom module, see gure .
• Remove the module, see gure .
• Connect the 2 cables "SENS" and "PUMP" of the pH Link or Dual Link module to the chlorinator's terminals,
see gure .
• Posion the module on the chlorinator according to step and screw (x2) according to step , see
gure .
• Replace the cover, see gure .
