3.5 I Installing the pH minus injecon and sucon hoses
• When handling chemical products, always use appropriate safety equipment
(safety glasses, gloves and jacket).
The peristalc pump rotates in the clockwise direcon. The acid (pH minus) is therefore fed into the le side of the pump
and injected into the tank from the right. The direcon of ow of the pump can be idened on the pH Link or Dual Link
module from the two dedicated arrows.
pH Link
Dual Link
POD kit
INPUT
OUTPUT
: Support p
: Ceramic weight
: pH minus container
: Sucon hose
: Peristalc pump
: Injecon hose
: Injecon check valve
3.5.1 Installing the pH minus injecon line
• Remove the protecve cover from the peristalc pump, see gure .
• Cut a suitable length of hose from the coil supplied to connect the peristalc pump to the injecon check
valve of the POD kit.
• Unscrew the connector cap and aach the hose to the connector at the outlet of the peristalc pump, see
gure
.
• Aach the other end of the hose to the injecon check valve of the POD kit, see gure .
