3.5.2 Installing the pH minus sucon line
• Cut a suitable length of hose from the coil supplied to connect the container of pH minus to the peristalc
pump.
• Unscrew the connector cap and aach the hose to the connector at the outlet of the peristalc pump, see
gure . Screw the cap in place.
• Reposion the protecve cover on the peristalc pump.
• Drill two holes into the cap of the pH minus container, see gure :
- One hole suited to the diameter of the hose to aspirate the product.
- One smaller hole to prevent the container from becoming deformed during aspiraon of the product.
• Pass the free end of the hose through the hole made in the cap and put the ceramic weight provided and
the support p on the hose, see gure .
• Ensure that ALL connecons are correct and waterght before operang the appliance.
Do not place the pH minus container directly beneath electrical equipment in the technical room to prevent
risk of corrosion resulng from potenal acidic vapours.
