3.2.3 Installing the POD kit on the pipe
• For a Ø50 mm pipe, use the adapter labelled "EU". Clip the 2 parts of the POD kit collar together around the
pipe. Make sure that the adapter is properly centred according to the guides; the adapter must stay in this
posion once all parts have been assembled. Do not use this adapter for a Ø63 mm pipe, see gure .
• Install the boom and top collars of the POD kit on the pipe according to the posion of the holes and the
water ow direcon (follow the arrows), see gure .
• Posion the top part with its dierent components in the direcon shown by the foolproong key, align the
point of the compression ring with the arrow of the boom collar and ghten the compression ring
well (ghten by hand only!), see gure .
• To determine whether ghtening is correct, check that the compression ring is level, see gure .
Pipe adapter Ø50 mm (marked "EU")
Boom collar Ø63
INPUT
OUTPUT
Direcon of water ow
Foolproong key
