■ MAIN OUT /SUB OUT Setting Screen
The levels of MAIN OUT/SUB OUT are displayed and you can set/adjust the output setting such as ON/OFF,
standard output level/limiter setting, level adjusting, etc.
❶
Status icon
This icon shows the recording status.
• : Stopped
• : Recording
• : Paused (during recording)
• : Playing
• : Paused (during playing)
❷
Counter
This shows the elapsed recording time (during recording) or playback time (during playing).
❸
Frame rate
• INT: internal timecode enabled
• EXT: external input timecode enabled
❹
Timecode
This shows the recording/playing timecode.
❺
Power type and remaining power
When the remaining battery charge becomes low, change the batteries (→Installing batteries), connect
an AC adapter (→Connecting an AC adapter) or connect an external DC power supply. (→Using an
external DC power supply)
Power type
• DC: AC adapter
19
