ZXV10 W615 User Manual
Confidential and Proprietary Information of ZTE CORPORATION 17
Parameter Description
TxBF Enable Enables or disables beam forming technology.
If Network card 2 is selected, see the figure below for the configuration
page. For a description of the parameters, refer to the following table.
Parameter Description
Network Card Select network card 2.
Enable Wireless RF Enables or disables the WLAN RF function.
Enable Isolation Enables or disables the SSID isolation function.
Mode Supports IEEE 802.11a Only, IEEE 802.11n Only, and
Mixed(802.11a+802.11n). The default is
Mixed(802.11a+802.11n).
Country/Region United States of America.
Band 5G
Band Width The options are 20 MHz, 40 MHz, and automatic.
