14.9 VPN Rules (IKE): Network Policy Move
Click the move ( ) icon in the VPN Rules (IKE) screen to display the VPN Rules (IKE):
Network Policy Move screen.
A VPN (Virtual Private Network) tunnel gives you a secure connection to another computer or
network. Each VPN tunnel uses a single gateway policy and one or more network policies.
• The gateway policy contains the IKE SA settings. It identifies the IPSec routers at either
end of a VPN tunnel.
• The network policy contains the IPSec SA settings. It specifies which devices (behind the
IPSec routers) can use the VPN tunnel.
Use this screen to associate a network policy to a gateway policy.
Figure 170 SECURITY > VPN > VPN Rules (IKE) > Move Network Policy
The following table describes the labels in this screen.
Table 68 SECURITY > VPN > VPN Rules (IKE) > Move Network Policy
LABEL DESCRIPTION
Network Policy
Information
The following fields display the general network settings of this VPN policy.
Name This field displays the policy name.
Local Network This field displays one or a range of IP address(es) of the computer(s) behind the
ZyWALL.
Remote Network This field displays one or a range of IP address(es) of the remote network behind
the remote IPsec router.
Gateway Policy
Information
Gateway Policy Select the name of a VPN rule (or gateway policy) to which you want to associate
this VPN network policy.
If you do not want to associate a network policy to any gateway policy, select
Recycle Bin from the drop-down list box. The Recycle Bin gateway policy is a
virtual placeholder for any network policy(ies) without an associated gateway
policy. When there is a network policy in Recycle Bin, the Recycle Bin gateway
policy automatically displays in the VPN Rules (IKE) screen.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard all changes and return to the main VPN screen.
