H7016 User Manual
4-26
② SENSOR
In this Sensor menu the user can configure the sensor inputs and the alarm outputs.
Sensor : On a 16 channel DVR there are up to 16 sensor inputs. Use the menu to set the
sensor type which will either be N/O (Normal Open) and N/C (Normal Close).
Alarm : On the DVR there are 4 outputs for alarm, set if the alarm requires a signal On/Off.
Also in this menu set the alarm type N/O or N/C.
