140 CHAPTER 7: ACL CONFIGURATION
Only one monitor port can be configured on one Switch. If a group of Switches
form a Fabric, only one monitor port can be configured on one Fabric.
2 Configure traffic mirroring
Perform the following configuration in the Ethernet Port View.
Table 141 Configuring Traffic Mirroring
Delete Traffic Mirroring
1 Delete traffic mirroring
Perform the following configuration in the Ethernet Port View.
Table 142 Delete Traffic Mirroring
2 Delete monitor port.
Perform the following configuration in the Ethernet Port View.
Table 143 Delete Monitor Port
For details about the command, refer to the Command Reference Guide.
Configuring the Mapping Relationship Between COS and Local Precedence
The default mapping relationship between 802.1p priority and output queue of
the port is as follows:
Table 144 Mapping between 802.1p Priority Levels and Outbound Queues
Perform the following configuration in System View.
Operation Command
Configure traffic mirroring mirrored-to { inbound | outbound } {
user-group acl_number [ rule rule ] | ip-group
acl_number [ rule rule [ link-group acl_number
rule rule ] ] | link-group acl_number [ rule
rule ] } { cpu | monitor-interface }
Operation Command
Cancel the
configuration of traffic
mirroring
undo mirrored-to { inbound | outbound } {
user-group acl_number [ rule rule ] | ip-group
acl_number | acl_name } [ rule rule ] | link-group
acl_number rule rule ] }
Operation Command
Delete monitor port undo monitor
802.1p priority level Queues
0 2
1 0
2 1
3 3
4 4
5 5
6 6
7 7
