BFB-3000 Set Up and Operations Manual
Document No: D100253 32
 Reel positions for each extruder are indicated below:
 Delivery tubes for each extruder run from right to left, as indicated below:
Figure 5: Reel positions and delivery tubes
Reel position
for Extruder 1
Reel position
for Extruder 2
Reel position
for Extruder 3
Tube for
Extruder 2
Tube for
Extruder 3
Tube for
Extruder 1
