Running studies
Starting a run
34
Running studies
With a couple pushes on the keypad buttons, you will be running and viewing your study (ies). Following
your study (ies), you can load the data/files into DMS to manipulate, analyze, save, and create reports (See
Chapter 5 for viewing your logged data in DMS).
Starting a run
 How to run a noise study
1. If your dosimeter is turned off, press the button to power on.
2. Press and hold the button.
 A 3, 2, 1 countdown will appear.
3. When running, the following will appear:
 A run indicator will appear on the top-right side.
 The LED indicator will flash green (unless you disabled this in DMS.)
Figure 4-8: Display screen while running
Run indicator
Appears when running
Battery indicator
Flashing green LED
indicates running
Measurements
 Use up/down arrow
to move through
values.
 Views are
customizable via
DMS setup
