338 | Managing the Radio
Aprisa SR+ User Manual 1.11.1
Network Status > View
This page provides a complete list of all registered remote radios. It is similar to the Exceptions page but it
shows all radios, not limited to the radios with alarms. When open, it provides a continuous monitor of the
network.
NETWORK VIEW
A network poll will start when any of the Network Status pages are opened (Summary, Exceptions or View).
The network poll will only continue to poll the remote radios if one of the Network Status pages is open
(SuperVisor can lose PC focus). The network poll continues from where it was stopped last time it was
polling.
Network View Example:
Result
Function
Network Polling Cycle
The number of poll cycles since first opening a Network Status >
Summary, Exceptions or View page.
Remote Radios Polled
This shows the number of remote radios polled for the current
polling cycle out of the number of remote radios registered with
the base station.
External Radios Polled
This shows the number of extended network radios polled for the
current polling cycle out of the total extended network radios.
Polling Interval
The time interval between the completion of one radio poll and
the start of the next radio poll. To set the polling interval, see
‘Maintenance > General’ on page 261.
Note: as this polling feature utilizes air time, the polling interval
should be selected to suit the network traffic.
