Instantaneous values
All registers in the following table are read only:
Quantity
Details
Start
Size
Res.
Unit
Value range
Data
reg
type
(Hex)
Voltage
L1-N
5B00
2
0,1
V
Unsigned
Voltage
L2-N
5B02
2
0,1
V
Unsigned
Voltage
L3-N
5B04
2
0,1
V
Unsigned
Voltage
L1-L2
5B06
2
0,1
V
Unsigned
Voltage
L3-L2
5B08
2
0,1
V
Unsigned
Voltage
L1-L3
5B0A
2
0,1
V
Unsigned
Current
L1
5B0C
2
0,01
A
Unsigned
Current
L2
5B0E
2
0,01
A
Unsigned
Current
L3
5B10
2
0,01
A
Unsigned
Current
N
5B12
2
0,01
A
Unsigned
Active power
Total
5B14
2
0,01
W
Signed
Active power
L1
5B16
2
0,01
W
Signed
Active power
L2
5B18
2
0,01
W
Signed
Active power
L3
5B1A
2
0,01
W
Signed
Reactive power
Total
5B1C
2
0,01
var
Signed
Reactive power
L1
5B1E
2
0,01
var
Signed
Reactive power
L2
5B20
2
0,01
var
Signed
Reactive power
L3
5B22
2
0,01
var
Signed
Apparent power
Total
5B24
2
0,01
VA
Signed
Apparent power
L1
5B26
2
0,01
VA
Signed
Apparent power
L2
5B28
2
0,01
VA
Signed
Apparent power
L3
5B2A
2
0,01
VA
Signed
Frequency
5B2C
1
0,01
Hz
Unsigned
Phase angle power
Total
5B2D
1
0,1
°
-180°-+180°
Signed
Phase angle power
L1
5B2E
1
0,1
°
-180°-+180°
Signed
Phase angle power
L2
5B2F
1
0,1
°
-180°-+180°
Signed
Phase angle power
L3
5B30
1
0,1
°
-180°-+180°
Signed
Phase angle voltage
L1
5B31
1
0,1
°
-180°-+180°
Signed
Phase angle voltage
L2
5B32
1
0,1
°
-180°-+180°
Signed
Phase angle voltage
L3
5B33
1
0,1
°
-180°-+180°
Signed
Phase angle current
L1
5B37
1
0,1
°
-180°-+180°
Signed
Phase angle current
L2
5B38
1
0,1
°
-180°-+180°
Signed
Phase angle current
L3
5B39
1
0,1
°
-180°-+180°
Signed
Power factor
Total
5B3A
1
0,001
-
-1,000-+1,000
Signed
Power factor
L1
5B3B
1
0,001
-
-1,000-+1,000
Signed
Power factor
L2
5B3C
1
0,001
-
-1,000-+1,000
Signed
