ACS 160 User’s Manual 13
J Routing the Motor Cables
Note! The motor cable outputs are located in different places depending on whether the unit is
going to be mounted on the wall or on the motor.
Wall mounting
Note! For cable selection and ensuring installation compatibility with the EMC instructions, see
Appendix C for EMC Instructions and Maximum Cable Lengths.
Motor mounting
U2, V2, W2
U
V
W
PE
U
V
W
PE
U2, V2, W2
