56 ACS 160 User’s Manual
Group 01: Operating Data
This group contains drive operating data, including actual signals and fault memories. Actual Signal
values are measured or calculated by the drive and they cannot be set by the user. Fault memories
can be cleared by the user from the control panel.
Code Description
0102 SPEED
Displays the calculated speed of the motor (rpm).
0103 OUTPUT FREQ
Displays the frequency (Hz) applied to the motor. (Also shown in OUTPUT display.)
0104 CURRENT
Displays the motor current, as measured by the ACS 160.
(Also shown in OUTPUT display.)
0105 TORQUE
Output torque. Calculated value of torque on motor shaft in % of motor nominal torque.
0106 POWER
Displays the measured motor power in kW.
Note! The control panel will not display the unit (“kW”).
0107 DC BUS VOLTAGE
Displays the DC bus voltage, as measured by the ACS 160. The voltage is displayed in Volts DC.
0109 OUTPUT VOLTAGE
Displays the voltage applied to the motor.
0110 ACS TEMP
Displays the temperature of the ACS 160 heatsink in Centigrade.
0111 EXTERNAL REF 1
The value of external reference 1 in Hz.
0112 EXTERNAL REF 2
The value of external reference 2 in %.
0113 CTRL LOCATION
Displays the active control location. Alternatives are:
0 =
LOCAL
1 = EXT1
2 =
EXT2
See chapters Local and Remote Control and Appendix A, for description of different control locations.
0114 RUN TIME (R)
Shows the total running time of the ACS 160 in hours (h). Can be reset by pressing UP and DOWN buttons
simultaneously when in parameter set mode.
0115 kWh COUNTER (R)
Shows the counted kilowatt hours of the ACS 160 in operation. Can be reset by pressing UP and DOWN
buttons simultaneously when in parameter set mode.
0116 APPL BLK OUTPUT
The reference value in per cent received from the application block. The value is from PID control.
Otherwise the value is from 0112
EXT REF 2.
0117 DI1-DI4 STATUS
Status of the four digital inputs. Status is displayed as a binary number. If the input is activated, the display
will indicate 1. If the input is deactivated, the display will be 0.
DI 4
DI 3
DI 2 DI 1
