ABB ACS 160 - Start-Up

ACS 160 User’s Manual 23
Start-up
The safety instructions must be followed at all times during the start-up procedure, see
Safety.
Note! Check that starting the motor does not cause any danger.
1. Apply mains power
2. Check Parameters
The first time the drive is powered up, it is controlled from
the Control Terminals (remote control, REM).
To switch to control panel use (local control, LOC), press
and hold the MENU and ENTER buttons down
simultaneously until first Loc is displayed.
ENTER
MENU
LOC REM
LOC
0.0
FWD
Hz
OUTPUT
REM
0.0
OUTPUT
Hz
FWD
Motor 3~ Cl. F IP55 IEC34
M2AA 080A 3GAA 082 001-ASA
ABB Motors
V Hz r/min kW A Cos ϕ
ϕϕ
ϕ
380-420 Y 50 1420 0.55 1.5 0.74
220-240 D 50 1420 0.55 2.6 0.74
440-480 Y 60 1700 0.65 1.5 0.73
9612100409
The following parameters must be set
using the information from the motor
name plate (see example on right).
9905
MOTOR NOM VOLT
9906 MOTOR NOM CURR
9907 MOTOR NOM FREQ
9908 MOTOR NOM SPEED
9909 MOTOR NOM POWER
9910 MOTOR COS PHI
