Group 32: Supervision
Parameters of this group are used together with relay output parameters 1401 RELAY OUTPUT 1 and
1402
RELAY OUTPUT 2. Any two parameters of the Operating Data group (Group 1) can be
supervised. Relays can be configured to be energised when the values of supervised parameters are
either too low or too high.
Code Description
3201 SUPERV 1 PARAM
First supervised parameter number of the Operating Data group (Group 01).
3202 SUPERV 1 LIM LO
First supervision limit low. Display of this parameter depends on selected supervised parameter (3201).
3203 SUPERV 1 LIM HI
First supervision limit high. Display of this parameter depends on selected supervised parameter (3201).
3204 SUPERV 2 PARAM
Second supervised parameter number of the Operating Data group (Group 01).
3205 SUPERV 2 LIM LO
Second supervision limit low. Display of this parameter depends on selected supervised parameter (3204).
3206 SUPERV 2 LIM HI
Second supervision limit high. Display of this parameter depends on selected supervised parameter (3204).
