ABB ACS 160 - Parameter Guide

ACS 160 User’s Manual 45
Parameter Guide
Group Name Description
99 Start-up Data Parameter settings for setting up the drive and for
entering motor information.
01 Operating Data Read only parameters for drive operation data, including
actual signals and fault memories.
10 Command Inputs Parameter settings for start, stop and direction
commands.
11 Reference Select Parameter settings for reference commands / locations.
12 Constant Speeds Parameter settings for constant speed value input.
13 Analogue Input Parameter settings for max, min and filter for the
analogue input.
14 Relay Outputs Parameter settings for relay output characteristics.
15 Analogue Outputs Parameter settings for analogue output.
16 System Controls Parameter settings for enabling/disabling parameter
access, run enable etc.
20 Limits Parameter settings for limiting operating features and
overvoltage control.
21 Start/Stop Parameter settings for selecting start and stop modes,
flying start, torque boosting, DC hold, ramp coast etc.
22 Acc/Decel Parameter settings for defining the two acceleration/
deceleration ramp pairs.
25 Critical Freq Parameter settings for setting critical freq to avoid
resonance problems.
26 Motor Control Parameter settings for selecting motor control features,
like IR compensation and low noise u/f ratio.
30 Fault Functions Parameter settings for configuring desired response to
certain abnormal external conditions.
31 Automatic Reset Parameter settings for automatically resetting some
faults.
32 Supervision Parameter settings for any 2 parameters of group 01 to
be supervised in co-operation with relays.
33 Information Read only parameters for information about the
software version and production date.
34 Process Variables Parameter settings for creating custom process
variables.
40 PID Control Parameter settings for the first set of PID Control
parameters.
41 PID Control (2) Parameter settings for the second set of PID Control
parameters.
51 Ext Comm Module Parameter settings for external fieldbus communication
modules.
52 Standard Modbus Parameter settings for standard Modbus (serial
communication).
54 Braking Parameter settings for selecting additional braking
features.
81 Positioning Parameter settings for positioning applications.
Set-up
Operating
Configuration
Performance
Information
Supervision
PID
Fieldbus
Braking
Positioning
