26 ACS 160 User’s Manual
6. Start the Drive from I/O
7. Stop the drive from I/O
Switch on the mains.
Make sure panel display is on remote control (REM). If not switch to
remote control by pressing MENU and ENTER simultaneously until
REM is displayed.
To start the drive activate digital input DI 1 (Factory macro 0).
As default digital input DI 2 is deactivated and the rotation direction
is forward. To reverse the rotation direction activate DI 2.
Output frequency is controlled by analogue input AI 1.
For further information on I/O settings, refer to the section on
Application Macros.
REM
0.0
OUTPUT
Hz
FWD
To stop the drive deactivate digital input DI 1 (Factory macro 0).
