24 Basic operation
Common user tasks
This following tables list common user tasks and describes how to complete them.
See Functions in the main Menu and Functions in the Options menu for detailed
descriptions of functions in the menus.
Basic operation of the drive
Parameters
System information and help
Task Actions
Start and stop the drive. In local control, press to start the drive and
to stop the drive.
Set the reference (for example, speed) in
the Home view.
In local control, go to Options > Reference. Set
the reference with the arrow keys. For detailed
instructions, see Setting the reference on page 38.
Switch between local and remote control. Press .
Change the direction of motor rotation. In local control, go to the Home view, press
(Options) to open the Options menu and select
Direction change.
Task Actions
Choose parameters displayed on the
Favorites list.
Go to Menu > Parameters > Favorites > Edit.
See also Editing the list of favorites on page 28.
View/edit parameters. Go to Menu > Parameters to view parameters.
See Editing parameters on page 29 for
instructions on editing parameters.
Add parameters to the Home view. See Editing the contents of the Home view on
page 38.
Show/hide parameter index and group
numbers.
Press + .
Restore parameter default value. In the editing mode, press + .
To save the default value, press (Save).
View parameters that differ from
Application Macro defaults.
Go to Menu > Parameters > Modified.
Task Actions
How to get help. Press to open the context-sensitive help.
View control panel version. Go to Menu > System info > Control panel.
View drive information. Go to Menu > System info > Drive.
Assistant Panel Guide Rev B.book Page 24 Tuesday, April 10, 2012 12:08 PM
