10 PREVENTIVE AND CORRECTIVE MAINTENANCE
3BHS799208 E01 REV E ACS5000 WATER-COOLED USER MANUAL 162/186
Figure 10-1 Device identification
10.2.2 Cables and wires
Cables and wires in the drive are equipped with marker sleeves that carry
the same identifying number as on the wiring diagrams.
Figure 10-2 Cable and wire designation
10.2.3 Understanding wiring diagrams
For information on item designation and cross-reference conventions, see
“Appendix D – Wiring diagrams”.
(1) Terminal number (2) Wire number
