ABB DCS 400 - Page 173

II K 7-15
Serial Interfaces
PROFIBUS Modbus, CAN-BUS DCS400 DCS-400 Par.Name Remark
Par. No Modbus+ Par.No. 6 - Input/Output
265 40601 3259 601 AI1 Scale 100%
266 40602 325A 602 AI1 Scale 0%
267 40603 325B 603 AI2 Scale 100%
268 40604 325C 604 AI2 Scale 0%
269 40605 325D 605 AO1 Assign
270 40606 325E 606 AO1 Mode
271 40607 325F 607 AO1 Scale 100%
272 40608 3260 608 AO2 Assign
273 40609 3261 609 AO2 Mode
274 40610 3262 610 AO2 Scale 100%
275 40611 3263 611 DO1 Assign
276 40612 3264 612 DO2 Assign
277 40613 3265 613 DO3 Assign
278 40614 3266 614 DO4 Assign
279 40615 3267 615 DO5 Assign
280 40616 3268 616 Panel Act 1
281 40617 3269 617 Panel Act 2
282 40618 326A 618 Panel Act 3
283 40619 326B 619 Panel Act 4
284 40620 326C 620 Dataset 2.2 Ass
285 40621 326D 621 Dataset 2.3 Ass
286 40622 326E 622 MSW Bit 11 Ass
287 40623 326F 623 MSW Bit 12 Ass
288 40624 3270 624 MSW Bit 13 Ass
289 40625 3271 625 MSW Bit 14 Ass
290 40626 3272
626 AI1 Act
291 40627 3273
627 AI2 Act
292 40628 3274
628 DI Act
PROFIBUS Modbus, CAN-BUS DCS400 DCS-400 Par.Name Remark
Par. No Modbus+ Par.No. 7 - Maintenance
298 40701 32BD 701 Language
299 40702 32BE 702 Contr Service
300 40703 32BF
703 Diagnosis
301 40704 32C0
704 SW Version
302 40705 32C1
705 Conv Type
303 40706 32C2
706 Conv Nom Cur
304 40707 32C3
707 Conv Nom Volt
305 40708 32C4
708 Volatile Alarm
306 40709 32C5
709 Fault Word 1
307 40710 32C6
710 Fault Word 2
308 40711 32C7
711 Fault Word 3
309 40712 32C8
712 Alarm Word 1
310 40713 32C9
713 Alarm Word 2
311 40714 32CA
714 Alarm Word 3
312 40715 32CB 715 Commis Ref 1
313 40716 32CC 716 Commis Ref 2
314 40717 32CD 717 Squarewave Per
315 40718 32CF
718 Squarewave Act
316 40719 32D0
719 Pan Text Vers
317 40720 32D1
720 CPU Load
318 40721 32D2
721 CON-Board
