Overview of Software
ParNo. Parameter name and significance Min Max Default Unit (1)
custom.
setting
Grp 5 Speed Controller (continued)
5.15
Wizard
Zero Speed Lev
Zero speed signal. Speed level below which the
signal is issued that the motor has reached zero
speed.
Is used for stall protection, as a standstill message
to the drive logic and for the generation of the Zero
Speed signal.
0 100 50 rpm
5.16
Wizard
Speed Level 1
Speed limit value for "Speed 1 reached" signal.
Is used as "speed reached" message for the macros
5 / 6, field bus status Above Limit 1 and the
generation of the Speed L1 signal.
0 6500 0 rpm
5.17
Wizard
Speed Level 2
Speed limit value for "Speed 2 reached" signal.
Is used as "speed reached" message for macro 6
and the generation of the Speed L2 signal.
0 6500 0 rpm
5.18 Overspeed Trip
Overspeed signal tripping value.
If the actual speed value exceeds the threshold
defined with this parameter the drive will switch off
with the fault message Overspeed (F18). Possible
causes for Overspeed are described in the chapter
Troubleshooting.
100 125 115 %
5.19 Jog Accel Ramp
Duration of the acceleration ramp for jogging in the
case of acceleration from 0 to maximum speed
(1.06).
Used for Fixed Speed 1 (5.13) or Fixed Speed 2
(5.14). Is also used for the macros 1 / 2 / 3 / 4 / 5 /
6 / 7.
0.0 3000.0 10.0 s x
5.20 Jog Decel Ramp
Duration of the deceleration ramp for jogging in the
case of deceleration from maximum speed (1.06) to
0.
Used for Fixed Speed 1 (5.13) or Fixed Speed 2
(5.14). Is used for the macro 1 / 2 / 5.
0.0 3000.0 10.0 s x
5.21 Alt Par Sel
Selection of the alternative parameter set:
0 = disabled, i.e. standard parameter set
permanently selected
1 = enabled, i.e. alternative parameter set
permanently selected
2 = Macro depend / dependent on the selected
macro
3 = Sp < Lev1 /
Actual speed < Speed level 1 (5.16)
4 = Sp < Lev2 /
Actual speed < Speed level 2 (5.17)
5 = Sp Err<Lev1 /
Speed error < Speed level 1 (5.16)
6 = Sp Err<Lev2 /
Speed error < Speed level 2 (5.17)
*(7 = Sp Ref<Lev1 /
Speed ref. < Speed level 1 (5.16))
*(8 = Sp Ref<Lev2 /Speed ref. < Speed level 2 (5.17))
* not yet released
For items 2...8, the alternative parameter set is
selected in dependence on the defined event.
0 8 2 Text
