II K 4-67
Overview of Software
ParNo. Parameter name and significance Min Max Default Unit
(1)
custom.
setting
Grp 7 Maintenance (continued)
7.03
Signal
Diagnosis
Display of all diagnostic messages:
Further information see chapter ’Troubleshooting’
0 = none
1…10 = 1…10 (internal software causes)
11 = Tune Aborted
12 = No Run Cmd
13 = No ZeroSpeed
14 = Fld Cur <> 0
15 = Arm Cur <> 0
16 = Arm L Meas
17 = Arm R Meas
18 = Field L Meas
19 = Field R Meas
20 = TuneParWrite
21 = 21 (internal software causes)
22 = Tacho Adjust
23 = Not Running
24 = Not At Speed
25 = TachPolarity
26 = Enc Polarity
27 = No EncSignal
28 = StillRunning
29 = 29 (internal software causes)
30 = Wiz ParWrite
31 = 31 (internal software causes)
32 = UpDn Aborted
33 = reserved
34 = Par Checksum
35 = 35 (internal software causes)
36 = 36 (internal software causes)
37…69 = reserved
70 = Fld Low Lim
71 = Flux Char
72 = Field Range
73 = Arm Data
74 = AI2 vs PTC
75 = RecoveryTime
76 = Grp9 Disable
77…79 = reserved
80 = Speed does not reach setpoint
81 = Motor is not accelerating
82 = Not enough measurement for speed KP and TI
83…89 = reserved
90 = Shortcut V11
91 = Shortcut V12
92 = Shortcut V13
93 = Shortcut V14
94 = Shortcut V15
95 = Shortcut V16
96 = Result False
97 = ShortcV15/22
98 = ShortcV16/23
99 = ShortcV11/24
100 = ShortcV12/25
101 = ShortcV13/26
102 = ShortcV14/21
103 = Ground Fault
104 = NoThrConduc
---Text
7.04
Const.
SW Version
Display of the DCS 400 software version used.
---integer
7.05
Const.
Conv Type
Display of the converter type:
0 = DCS401 (2Q)
1 = DCS402 (4Q)
2 = DCS401 Rev A (2Q)
3 = DCS402 Rev A (4Q)
---Text
(1) no changes possible if the drive is in ON-status
