Power Line Carrier Equipment: Series ETL500/ETL600
Instruction for Changing the Input Voltage of B5LC
Contents
1
Purpose of document...................................................................................... 1
2 Safety instructions .......................................................................................... 1
3 Changing from 230 VAC to 115 VAC ............................................................. 2
4 Changing from 115 VAC to 230 VAC ............................................................. 2
1 Purpose of document
This document describes how to change the input voltage of the AC power supply type B5LC from
230 VAC to 115 VAC or vice versa.
2 Safety instructions
DANGER
Hazardous voltage and hazardous energy level.
Beware of electric shock.
Unplug the cables to the module from the mains before opening.
Caution
Follow the instruction below carefully and do not modify anything.
Caution
Wrong programming can damage the module and the equipment.
Check if programmed input voltage of the module is equal to the mains
voltage.
Verify the programming information on the right side of the module.
Caution
Operate the module only in the condition specified by the manufacturer.
third parties without express authority is strictly forbidden. © ABB Switzerland Ltd
