Mounting
D184B140U02 FSM4000 25
Meter size DN Nominal
pressure
Max. tightening torque [Nm]
mm Inch PN Hard/soft rubber lining ETFE lining
Steel flange Stainless steel
flange
Steel flange Stainless steel
flange
800 32“
PN10 391.7 304.2 On request On request
PN16 646.4 511.8 On request On request
PN25 1358 1087 On request On request
CL150 410.8 380.9 493.3 380.9
CL300 2187 On request On request On request
900 36“
PN10 387.7 296.3 On request On request
PN16 680.8 537.3 On request On request
PN25 1399 1119 On request On request
CL150 336.2 394.6 511 458.5
CL300 1972 On request On request On request
1000 40“
PN10 541.3 419.2 On request On request
PN16 955.5 756.1 On request On request
PN25 2006 1612 On request On request
CL150 654.2 598.8 650.6 385.1
CL300 2181 On request On request On request
4.4.2 Variable process connections model SE21
Meter size DN Max. tightening torque
mm inch Nm
1 ... 2 1/25 ... 3/32“ PVC/POM: 0,2 Messin
g
/1.4571: 3
3 ... 10 3/8“ 8
15 1/2“ 10
20 3/4“ 21
25 1 31
32 1 1/4“ 60
40 1 1/2“ 80
50 2 5
65 2 1/2“ 5
80 3 15
100 4 14
