Parameterization
94 FSM4000 D184B140U02
7.4.3 Displaying the diagnostic values
7.4.3.1 Measurement values
A maximum of four diagnostic values can be displayed (Fprt1, Fprt2, Fprt3, Fprt4). Values can
be selected in the submenu Diagnostics / Fingerprint / Fprt1 - 4. In addition to the type of
measurement value, the desired data record has to be configured. Through the combination of
these two settings, every stored measured value can be displayed. To differentiate between the
values in the display an identification code (ID) is prefixed before to each value.
As a result, each line appears as follows:
e.g., CV_RCL 80.5 ohm for the current coil resistance.
CV _ RCL 80.5 ohm
Data record Type Numerical value Unit
CV_: Current value UAC: Coil voltage (AC) X.X V
H1_: History 1 IAC: Coil current (AC) X mA
H2_: History 2 RCL: Coil resistance Value > 100 X
Value < 100 X.X
Ohm
H3_: History 3 TCL: Coil temperature X °C
H4_: History 4 RIS: Insulation resistance Value > 100 X
Value < 100 X.X
MOhm
H5_: History 5 UE1: Electrode voltage E1 X µV
H6_: History 6 UE2: Electrode voltage E2 X µV
H7_: History 7 BAL: Electrode balance E1 ≥ E2 → +X
E1 < E2 → -X
%
%
H8_: History 8 LIN: Magnetic linearity X %
H9_: History 9 SNR: Signal-to-noise ratio X %
FV_: Factory Fingerprint DAC: Max. DAC value X Dig =
Digits
DF_: Startup Fingerprint
P1_: Product 1-Fingerprint
P2_: Product 2-Fingerprint
