7.4.2 Recommended settings for diagnostic limit values
The values indicated are only intended as a rough guide and may need to be adapted in line
with on-site conditions.
Parameter Minimum value Maximum value
Electrode volta
g
e 1 These values depend on the flowrate, so no recommendations can be made here.
Electrode volta
g
e 2
Electrode balance
1)
-150 % 150 %
Coil curren
t
Factor
y
or commissionin
g
fin
g
erprint x 0.95 Factor
y
or commissionin
g
fin
g
erprint x 1.05
Coil voltage This value depends on the fluid temperature T
medium
.
T
medium
T
medium
-40 °C
(
-40 °F
)
Factory fingerprint x 0.81
-40 °C
(
-40 °F
)
Factory fingerprint x 0.89
-20 °C
(
-4 °F
)
Factory fingerprint x 0.86
-20 °C
(
-4 °F
)
Factory fingerprint x 0.95
0 °C
(
32 °F
)
Factory fingerprint x 0.9
0 °C
(
32 °F
)
Factory fingerprint x 1
20 °C
(
68 °F
)
Factory fingerprint x 0.95
20 °C
(
68 °F
)
Factory fingerprint x 1.05
60 °C
(
140 °F
)
Factory fingerprint x 1.05
60 °C
(
140 °F
)
Factory fingerprint x 1.16
90 °C
(
194 °F
)
Factory fingerprint x 1.14
90 °C
(
194 °F
)
Factory fingerprint x 1.26
130 °C
(
266 °F
)
Factory fingerprint x 1.24
130 °C
(
266 °F
)
Factory fingerprint x 1.37
180 °C
(
356 °F
)
Factory fingerprint x 1.33
180 °C
(
356 °F
)
Factory fingerprint x 1.47
Coil resistance
This value depends on the fluid temperature T
medium
.
T
medium
T
medium
-40 °C
(
-40 °F
)
Factory fingerprint * 0.71
-40 °C
(
-40 °F
)
Factory fingerprint * 0.79
-20 °C
(
-4 °F
)
Factory fingerprint * 0.81
-20 °C
(
-4 °F
)
Factory fingerprint * 0.89
0 °C
(
32 °F
)
Factory fingerprint * 0.9
0 °C
(
32 °F
)
Factory fingerprint * 1
20 °C
(
68 °F
)
Factory fingerprint * 0.95
20 °C
(
68 °F
)
Factory fingerprint * 1.05
60 °C
(
140 °F
)
Factory fingerprint * 1.19
60 °C
(
140 °F
)
Factory fingerprint * 1.31
90 °C
(
194 °F
)
Factory fingerprint * 1.28
90 °C
(
194 °F
)
Factory fingerprint * 1.42
130 °C
(
266 °F
)
Factory fingerprint * 1.43
130 °C
(
266 °F
)
Factory fingerprint * 1.58
180 °C
(
356 °F
)
Factory fingerprint * 1.62
180 °C
(
356 °F
)
Factory fingerprint * 1.79
Coil temperature This value depends on the ambient / fluid temperature, so no recommendations can be
made here.
1) This function is only guaranteed if an electrode zero point adjustment has been carried out (see page 85).
