Safety
D184B140U02 FSM4000 9
1.5.2 Name Plate / Factory Tag
The factory tag or name plate can be found at the following locations on the unit housing:
G00522
3
1
2
Fig. 1
1 Name plate, flowmeter sensor
2 Factory tag plate, flowmeter sensor
3 Name plate, transmitter
1.5.2.1 Identifying the device design
1. Identifying the model:
The model number of the flowmeter sensor or transmitter (see nos. 1 or 2 in the description
of the name plates) can be found on the name plate. The connection diagram for the
respective model is contained in the section “Terminal connection diagrams”. Technical data,
material load curves, etc., are organized by model in the section “Technical data”.
2. Identifying the transmitter design:
The transmitter design can be identified from the name plate on the transmitter housing.
3. Identifying the software version:
The software version can be displayed when the transmitter is switched on.
