The parameter window Special day range is activated in the following way:
- by double-clicking on the selected special day or
- by pressing the right mouse button and selecting Edit in the pop-up menu.
Fig. 122: Parameter window: “Modify special day range”
The selected Special day range dialog is now available for editing.
Start, End, Day routine
The start, end and day routine can be edited.
Time at
The displays for hours and minutes can be edited separately via the buttons
Left arrow and Right arrow.
“OK” button
When the “OK” button is pressed, the settings are adopted and the parameter
window closes.
“Cancel” button
When the “Cancel” button is pressed, the function is aborted and the
parameter window closes.
“Help” button
The “Help” file can be opened directly via the “Help” button and a further
parameter window Help for application program… is opened.
