3.3.5.2 Communication objects Value/forced operation
No.
Functionality
communication object name
Data type
Flags
90
Block
Input a:
Value/forced operation
1 bit
DPT 1.003
C, W
This communication object is enabled if the parameter Input a has been selected with the option Value/forced operation in
Parameter window Enable inputs a…c, p. 170, and the parameter Enable communication object "Block" 1-bit has then been
selected with the option Yes in Parameter window a: Value/forced operation, p. 181.
Using the communication object Block, the input can be blocked or enabled. With activated communication object Block the
inputs are blocked.
Note
When the input is blocked there is fundamentally no reaction to a signal change, but:
 Waiting for a long button operation or a minimum signal duration is suspended.
 The parameter setting 8-bit scene ends saving.
 communication objects continue to be updated and sent if necessary.
When enabling an input, a change of the signal states (as opposed to before the block) leads to immediate
processing, e.g.:
 The minimum actuation or detection of a long/short button push starts.
 communication objects send their current value if necessary.
Telegram value:
0 = Enable input a
1 = Block input a
91
Value 1
Input a:
Value/forced operation
DPT variable
C, T
This communication object is enabled if the parameter Input a has been selected with the option Value/forced operation in
Parameter window Enable inputs a…c, p. 170.
This communication object sends a value on the bus with short operation when opening or closing the contact. The value and
data type can be freely set in the parameters.
1 bit value [0/1]
2 bit value [0…3]
1-byte value [-128...127]
1-byte value [0...255]
1-byte value (8-bit scene)
2-byte value [-32,768...32,767]
EIS 1
EIS 8
EIS 14
EIS 6
EIS 6
EIS 10
DPT 1.001 switch telegram
DPT 2.001 forced operation
DPT 6.010 value
DPT 5.010 value
DPT 18.001 control scene
DPT 8.001 value
2-byte value [0...65,535]
2 byte value [EIB floating point]
3 byte value [time, weekday]
4-byte value [0...4294967295]
EIS 10
EIS 5
EIS 3
EIS 11
DPT 7.001 value
DPT 9.001 temperature
DPT 10.001 time, weekday
DPT 12.001 value
4-byte value [-2147483648...2147483647]
EIS 11
DPT 13.001 value
92
Value 2
See communication object 91
93…99
Not assigned
100…119
Input b, c
