Commissioning
© 2006 ABB STOTZ-KONTAKT GmbH 119
ABB i-bus
®
EIB / KNX
3.4.8.1 Display overview
Note Before an overview is edited, group addresses must be linked
with day routines.
Fig. 128: Dialog window: “Display overview”
To display an overview, first select Time switch program in the selection area
followed by Overview.
The associated table is activated in the right-hand window.
The table is divided into Date, Time, Value, SoC and by day routine. The
parameter window contains the parameters Group address, Time frame and
the Show button.
The meaning of the individual columns and parameters is as follows:
