ABB i-bus EIB User Manual

ABB i-bus
®
KNX
Commissioning
210 2CDC508134D0202 | FCA/S 1.x.x.1
No.
Functionality
communication object name
Data type
Flags
9
2nd control value, cooling,
continuous (PWM)
Output A
1 byte
DPT 5.001
C, R
This communication object is enabled if a Fan Coil operating mode with two control values and one valve has been selected
in Parameter window Enable output A...D, p. 76, if the operating mode Valve drive, thermoelectric (PWM) has been selected
and the parameter Control value is received as has been parameterized with the option Byte in Parameter window A: Output
(Valve drive, thermoelectric (PWM)), p. 97.
The 2nd control value is set fixed to cooling.
The communication object value [0…255] determines the variable mark-to-space ratio of the valve drive. With
communication object value 0 the output switches OFF (valve is closed with normally closed valve drive). With
communication object value 255 the output switches ON permanently (valve is fully open with normally open valve drive).
Telegram value:
0 = OFF (valve drive closed)
x = Intermediate values
255 = ON (valve drive opened)
9
2nd control value, cooling,
continuous (3-point)
Output A/B
1 byte
DPT 5.001
C, R
This group operation is enabled if a Fan Coil operating mode with two control values and one valve has been selected in
Parameter window Enable output A...D, p. 76, and the operating mode Valve drive, motor-driven (3-point) has been
selected.
The 2nd control value is set fixed to cooling.
The communication object value [0…255] determines the control value of the valve drive.
If the communication object value is 0, the output switches OFF (voltage 0 V).
If the communication object value is 255, the output switches ON permanently (full voltage).
Telegram value:
0 = OFF (valve drive closed)
x = Intermediate values
255 = ON (valve drive opened)
9
2nd control value, cooling,
analog (0...10 V)
Output A
1 byte
DPT 5.001
C, R
See communication object 9 2nd control value, cooling, continuous (3-point)
