ABB i-bus EIB User Manual

ABB i-bus
®
KNX
Commissioning
FCA/S 1.x.x.1 | 2CDC508134D0202 209
No.
Functionality
communication object name
Data type
Flags
5
Fault (overload/short-circuit)
Output A
Output A/B
1 bit
DPT 1.005
C, R, T
If there is a fault on an output, e.g. due to a short-circuit or overload, the LED A and B will flash. The communication object
Fault (overload/short-circuit) simultaneously sends a telegram with the value 1.
In the event of a fault on output A and/or B, these two outputs are switched off.
After the fault has been fixed, the fault is reset via the communication object Reset malfunction and the communication
object hast the value 0.
If the fault still persists, the LED will flash again, and the communication object has the value 1.
Note
Signaling via LED occurs only for the devices FCA/S 1.1.2.2 and FCA/S 1.2.2.2.
The communication object is always visible.
Telegram value:
0 = No fault on the output.
1 = Fault on the output.
6
Reset malfunction
Output A
Output A/B
1 bit
DPT 1.015
C, W, T
A fault is reset via this communication object, e.g. short-circuit/overload LED flashes on the device.
Note
Signaling via LED occurs only for the devices FCA/S 1.1.2.2 and FCA/S 1.2.2.2.
A reset is only successful if the fault has been repaired and is no longer present.
The LED turns off after it is successfully reset.
There is no reaction should the value 1 be received during correct operation.
If a group address has not been assigned to this communication object, the fault can be reset when the device is restarted.
The communication object is always visible.
Telegram value:
0 = No function
1 = Reset malfunction
7
Fault (overload/short-circuit)
Output C
Output C/D
1 bit
DPT 1.005
C, R, T
See communication object 5
8
Reset malfunction
Output C
Output C/D
1 bit
DPT 1.015
C, W, T
See communication object 6
