After pressing the Accept button, a further dialog window Group address
becomes active. The data type for the newly created group address is
selected in this window.
Fig. 195: Parameter window: “Group member, Select data type”
“OK” button
When the “OK” button is pressed, the settings are adopted and the parameter
window closes.
“Cancel” button
When the “Cancel” button is pressed, the function is aborted and the
parameter window closes.
“Help” button
The “Help” file can be opened directly via the “Help” button and a further
parameter window Help for application program… is opened.
Note: The transfer of the newly created group address to ETS3 is only
carried out after exiting the ABZ/S parameterisation and after
confirming the prompt that the modified data should be saved.
The editing of the group addresses such as modification of the
description or deletion can only be carried out in ETS3.
